● Emperon™ print controller: Konica Minolta’s high-performance controller with support of PostScript3, PCL6, PCL 5e/c and XPS
● Smart job queue: Unprintable jobs e.g. because of unavailable paper size (copy, print and fax) are bypassed by consecutive jobs
● Carbon Copy print: Single page printing from multiple trays
● Advanced letter folding: Folding sets of up to 3 pages can be selected in the printer driver
● Direct print: Driverless printing of PDF, XPS, JPEG, TIFF, PS and PCL
● Custom function bar: Up to 2 x 7 copy functions can be freely selected for the main copy screen
● Blank page removal: Automatic deletion of blank pages e.g. when copying mixed simplex and duplex documents
● Job preview: Illustrates selected copy functions on screen
● Auto features: Auto colour/black and white recognition; auto paper side selection; auto zoom to paper size
● Copy Program: Registration of complete copy job settings for recurring jobs
● Dual Scan: front and backside of a document will be scanned in 1 pass
● Scan-to-Me/Home: Direct scan to own email address (Me) or SMB folder (Home) based on Active Directory information
● Scan preview: Provides a real-time preview of scanned originals for checking before sending
● Addressbook: MFP and network based address books can be used and searched
● Fax forwarding: Forwarding of incoming fax documents by email or to SMB folder instead of printing
● PC-Fax: Direct fax transmission from the PC
● IP-Fax: Sending of fax messages via network between Konica Minolta MFPs; supports colour as well as black & white
● Digital receipt: Incoming faxes can be stored as file in public or secure userboxes
● Fax separation: Output and paper tray can be selected for the fax print
● Box function: Storing of print, copy, scan and fax jobs for recall to send and print – for frequently printed documents like brochures, forms, pricelists etc.
● Personal, Group and Public: User access definition for different boxes
● Sharing: Copying of documents from user box to user box
● Online access: User box file access via web browser or box operator utility
● Authentication: User access by password, user name + password, ID card or fingervein scanner
● Data encryption: Encryption of data stored on hard disk and password protection for hard disk access
● Fully ISO-15408 EAL3 certified: Proven security
● Network security: Support for SSL/TLS, HTTPS, 802.1x and IPsec
● bizhub Secure: Konica Minolta Security consultancy and MFP setup
● Dynamic eco timer: Automatic analysis of working hours and adjustment of sleep mode timing
● Weekly timer: Sleep mode timer setting on day and date basis
● ECO meter: Counter for ECO related items e.g. power consumption
● Simitri HD toner: Includes biomass
● Induction Heating: IH fusing system with high efficiency and accuracy
● Finishing: Corner stapling, 2-point stapling, Two-hole punching, Four-hole punching, Duplex, Combined mixplex/ mixmedia, Sheet insertion, report, Letter fold, Booklet, Offset sorting, Banner printing, Z-fold, Half fold
Operating Systems: Windows 7, Windows Vista, Windows XP, Windows 2000, Mac OS, Linux, Citrix Ready
Copier Specifications
| Copying process | Electrostatic laser copy; Tandem; indirect |
|---|---|
| Toner system | Simitri HD®- polymerised toner |
| Copy/print speed A4 mono (cpm) | 75 |
| Copy/print speed A4 colour (cpm) | 60 |
| Copy/print speed A3 mono (cpm) | 37 |
| Copy/print speed A3 colour (cpm) | 30 |
| Autoduplex speed A4 mono (cpm) | 75 |
| Autoduplex speed A4 colour (cpm) | 60 |
| 1st Copy/print time mono (sec) | 3.6 |
| 1st Copy/print time colour (sec) | 5.3 |
| Warm-up time (sec) | Approx. 22 (Warm up time may vary depending on the operating environment and usage) |
| Copy resolution (dpi) | 600 x 600 |
| Gradations | 256 gradations |
| Original format | A5-A3 |
| Magnification | 25-400% in 0.1% steps; Autozooming |
| Copy functions | Chapter; Cover and page insertion; Proof copy (print and screen); Adjustment test print; Digital art functions; Job setting memory; Poster Mode; Image repeat; Overlay; Stamping; Copy Protection |
Printer Specifications
| Print resolution (dpi) | 1,800 x 600 dpi (standard) 1,200 x 1,200 dpi |
|---|---|
| Controller CPU Type | PowerPC MPC8536 |
| Controller CPU Speed | 1.2 GHz |
| Page description language | PCL 6c (PCL 5c + XL3.0); PostScript 3 (CPSI 3017); XPS |
| Operating systems | Windows 2000/XP/XP64 Windows VISTA 32/64 Windows 7 32/64 Windows Server 2000/2003/2003×64/2008/2008×64 Macintosh 9.x/10.x Unix/Linux/Citrix |
| Printer fonts | 80x PCL Latin; 137x PostScript 3 Emulation Latin |
| Print functions | Direct print of PCL, PS, TIFF, XPS, PDF, Encrypted PDF files and OOXML (docx, xlsx, pptx); Mixmedia and mixplex; Job programming “Easy Set”; Overlay; Watermark; Copy Protection |
Scanner Specifications
| Scan speed colour (opm) | up to 180 ipm |
|---|---|
| Scan Speed mono (opm) | up to 180 ipm |
| Scan resolution (dpi) | Max.: 600 x 600 |
| Scan modes | Network TWAIN scan; scan-to-email (scan-to-Me); scan-to-FTP; Scan-to-SMB (scan-to-Home); scan-to-Box; scan-to-WebDAV; scan-to-DPWS; scan-to-USB |
| File formats | JPEG; TIFF; PDF; PDF/A 1a and 1b (optional); Compact PDF; Encrypted PDF; Searchable PDF (optional); XPS; Compact XPS; PPTX and searchable PPTX (optional) |
| Scan destinations | 2,100 (single + group); LDAP support |
| Scan functions | Annotation (text/time/date) for PDF; up to 400 job programs; realtime scan preview |
Fax Specifications
| Fax standard | Super G3 (optional) |
|---|---|
| Fax transmission | Analogue; i-Fax; Colour i-Fax (RFC3949-C); IP-Fax |
| Fax resolution (dpi) | Max.: 600 x 600 (ultra-fine) |
| Fax compression | MH; MR; MMR; JBIG |
| Fax modem (Kbps) | Up to 33.6 |
| Fax destinations | 2,100 (single + group) |
| Fax functions | Polling; Time shift; PC-Fax; Receipt to confidential box; Receipt to email/FTP/SMB; up to 400 job programs |
User box specification
| Max. storable documents | Up to 3,000 documents or 10,000 pages |
|---|---|
| Type of user boxes | Public; personal (with password or authentication); group (with authentication) |
| Type of system boxes | Secure print; encrypted PDF print; fax receiving; fax polling |
| User box functionality | Reprint; combination; download; sending (email/FTP/SMB and Fax); copy box to box |
System Specifications
| System memory standard (MB) | 2,048 |
|---|---|
| System hard disc standard (GB) | 250 |
| Interfaces standard | 10/100/1,000-Base-T Ethernet USB 2.0 |
| Network protocols | TCP/IP (IPv4 / IPv6); IPX/SPX; NetBEUI; AppleTalk (EtherTalk); SMB; LPD; IPP; SNMP; HTTP |
| Frame types | Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP |
| Automatic document feeder | Up to 150 originals; A6-A3; 35-210 g/m²;Dual ADF |
| Paper size | A6-SRA3; customised paper sizes; banner paper max. 1,200 x 297 mm |
| Printable paper weight (g/m²) | 52 – 300 |
| Paper input capacity (sheets) | Standard: 3,650 Max: 6,650 |
| Paper trays standard | Tray 1: 500 sheets, A5-SRA3, 52-256 g/m² Tray 2: 500 sheets, A5-SRA3, 52-256 g/m² Tray 3: 1,500 sheets, A4, 52-256 g/m² Tray 4: 1,000 sheets, A4, 52-256 g/m² Manual Bypass: 150 sheets, A6-SRA3, custom sizes, banner, 52-300 g/m² |
| Paper trays optional | Large Capacity Cabinet (1): 3,000 sheets, A4, 52-256 g/m² Large Capacity Cabinet (2): 2,500 sheets, A4-SRA3, 52-256 g/m² |
| Automatic duplexing | A5-SRA3; 52-256 g/m² |
| Finishing modes (optional) | Offset; group; sort; staple; punch; post insertion, z-fold, centre-fold; letter-fold; booklet |
| Output capacity (w. finisher) | Max.: 3,200 sheets |
| Output capacity (w/o finisher) | Max.: 250 sheets |
| Stapling | Max. 100 sheets or 98 sheets + 2 cover sheets (up to 209 g/m²) |
| Stapling output capacity | Max. 1,000 sheets |
| Letter fold | Up to 3 sheets |
| Letter fold capacity | Max. 30 sheets (tray); unlimited |
| Booklet | Max. 20 sheets or 19 sheets + 1 cover sheet (up to 209 g/m²) |
| Booklet output capacity | Max. 100 sheets (tray); unlimited |
| Copy/print volume recommended (monthly) | 150,000 pages |
| Copy/print volume max. (monthly) | 275,000 pages |
| Toner lifetime Black | 47,500 |
| Toner lifetime CMY | 31,500 |
| Imaging Unit lifetime Black | 300,000/1,200,000 (Drum/Developer) |
| Imaging Unit lifetime CMY | 155,000 |
| Power consumption | Less than 2.1 KW (system) TEC* 5.66 *Typical Electricity Consumption (weekly) by Energy Star regulations |
| System dimensions (WxDxH, mm) | 650 x 799 x 1155 |
| System weight (kg) | Approx. 221 |
System Features
| Security | ISO 15408 EAL3 (in evaluation); IP filtering and port blocking; SSL2; SSL3 and TSL1.0 network communication; IPsec support; IEEE 802.1x support; user authentication; authentication log; Secure Print; Hard disc overwrite (8 standard types); Hard disc data encryption (AES 128); Memory data auto deletion; Confidential fax receiving; Print user data encryption; Copy Protection (copy guard, password) |
|---|---|
| Accounting | Up to 1,000 user accounts Active Directory support (user name + password + email + smb folder) User function access definition Biometric Authentication (finger vein) optional IC-Card authentication (IC-Card reader) optional |
| Software | PageScope Net Care Device Manager; PageScope Data Administrator; PageScope Box Operator; PageScope Direct Print; Print Status Notifier; Driver Packaging Utility; Log Management Utility |
